Antenna type

MIMO patch array

Operating frequency range

2400-2500 MHz
5250-5850 MHz

VSWR bandwidth

2:1

Peak gain (dBi)

2.4-GHz band: 13
5-GHz band: 7

Polarization, 2.4 GHz

Cable A: Vertical
Cable B: Horizontal
Cable C: Vertical

Polarization, 5 GHz

All antennas: Vertical

E-plane 3-dB beamwidth (degrees)

2.4-GHz: 36
5-GHz: 48

H-plane 3-dB beamwidth

2.4-GHz: 36
5-GHz: 55

Cable length

36 in. (91 cm)

Connectors

RP-TNC male

Length (Radome)

18 in. (45.7 cm)

Width (Radome)

13 in. (33 cm)

Thickness (Radome)

2 in. (5 cm)

Weight (antenna and bracket)

7.75 lbs. (3.52 kg)

Environmental Ratings

Water: IP65, dust and jetting water immunity

Ice: Mil-810F, Method 521.2

Wind: 100 mph operational

Operating Temperature:
-30 to 70 degrees C
(-22 to 158 degrees F)
